ISO Vertical Conveyor Cement Sand Belt Bucket Elevator

  • 1
  • 2

Brand Name : Green Eco-Equipment

Certification : ISO9001:2008/CE

Place of Origin : Henan, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20 sets per month

Delivery Time : 10~15 workdays after receiving fullpayment.

Packaging Details : In Bulk/As Customer's Requirement

Condition : New

Material : Carbon Steel

Voltage : 220V/380V/As Customer's Request

Material Feature : Heat Resistant

Structure : Hopper Bucket Elevator

Conveying material : Cement, coal, chemical

Application : Manufacturing Plant, Construction works , Energy & Mining

After-sales Service Provided : Field installation, commissioning and training

Contact Now

Vertical Conveyor Belt Bucket Elevator Cement Sand Elevator With High Quality



Product Description

Bucket elevator structure is suitable for vertical conveying of powder, granule and small materials.Bucket elevator has the advantages of simple structure, stable operation, high degree of improvement and long service life.
TD type bucket elevator is made up of a series of hoppers fixed to belt. It applies to vertically transporting materials, such as metallic and non-metallic ores(cement, coal, sand, gravel, limestone, etc.), food products( grain, flour, etc.), chemical processing products(fertilizers, phosphates, etc.), pulp and paper products(wood chips, etc.).
Our company also can design and manufacture customized models to meet customers’ needs.
ISO Vertical Conveyor Cement Sand Belt Bucket Elevator


Features

Type TD Type
Structural feature Use rubber belt as traction components
Unloading mode Discharge by centrifugal or hybrid method
Applicable material Powdery, granular and small, non-abrasive or semi-abrasive materials with a loose density less than 1.5t/m³.
Applicable temperature The temperature of materials transported by ordinary rubber belt shall not exceed 60℃, and the temperature shall not exceed 200℃ if by heat-resistant rubber belt.
Others It’s completely enclosed, which can prevent dust from leakage, not be affected by the weather. Low driving power, inflow feeding, induction unloading, high-volume hopper intensive arrangement.Long service life, it seldom occurs extrusion and collision events.


Main Parameters

Model Max. Feed Size Capacity Bucket Belt Width Hoisting Height
Width Pitch Volume Speed
(mm) (m3/h) (mm) (mm) (L) (m/s) (mm) (m)
TD160 25 5.4-16 160 280, 350 0.5-1.9 1.4 200 40
TD250 35 12-35 250 360, 450 1.3-4.6 1.6 300
TD315 45 17-40 315 400, 500 2-5.8 1.6 400
TD400 55 24-66 400 480, 560 3.1-9.4 1.8 500
TD500 60 38-92 500 500, 625 4.8-15 1.8 600
TD630 70 85-142 630 710 14-23.5 2 700


Applications

ISO Vertical Conveyor Cement Sand Belt Bucket Elevator

Details Show
ISO Vertical Conveyor Cement Sand Belt Bucket Elevator

Project Case
ISO Vertical Conveyor Cement Sand Belt Bucket Elevator
